FEMTO MEGA I ORBBEC IP65 cámara RGB y de profundidad de grado industrial multimodo programable con transmisión en tiempo real de imágenes
FEMTO MEGA I ORBBEC IP65 cámara RGB y de profundidad de grado industrial multimodo programable con transmisión en tiempo real de imágenes
Technical Specs
| Product Name | Femto Mega I |
|---|---|
| Wavelength | 850nm |
| Dimensions | 180mm x 50mm x 110mm |
| Technology | Time of Flight |
| Depth FoV | H 120° V 120° (WFOV) H 75° V 65° (NFOV) |
| RGB FoV | H 80° V 51° |
| Depth Resolution Framerate | Up to 1024X1024@15fps (WFOV) 640X576@30fps (NFOV) |
| RGB Resolution Framerate |
3840x2160 @Up to 25 FPS 1920x1080 @Up to 30 FPS |
| Range | *0.25-3.86m (depending on depth mode) |
| Weight | 1080g |
| Operating Systems | Windows/Linux |
| Power Consumption | Average < 11W |
| Data Output | Point Cloud, Depth Map, IR & RGB |
| Temperature |
0℃ - 45℃; Indoor/Semi-Outdoor; 8-90%RH (non-condensing) |
$5,992.56
FEMTO MEGA I ORBBEC IP65 cámara RGB y de profundidad de grado industrial multimodo programable con transmisión en tiempo real de imágenes—
$5,992.56
Description
Technical Specs
| Product Name | Femto Mega I |
|---|---|
| Wavelength | 850nm |
| Dimensions | 180mm x 50mm x 110mm |
| Technology | Time of Flight |
| Depth FoV | H 120° V 120° (WFOV) H 75° V 65° (NFOV) |
| RGB FoV | H 80° V 51° |
| Depth Resolution Framerate | Up to 1024X1024@15fps (WFOV) 640X576@30fps (NFOV) |
| RGB Resolution Framerate |
3840x2160 @Up to 25 FPS 1920x1080 @Up to 30 FPS |
| Range | *0.25-3.86m (depending on depth mode) |
| Weight | 1080g |
| Operating Systems | Windows/Linux |
| Power Consumption | Average < 11W |
| Data Output | Point Cloud, Depth Map, IR & RGB |
| Temperature |
0℃ - 45℃; Indoor/Semi-Outdoor; 8-90%RH (non-condensing) |
